Used Amate Audio DSP608 / DSP608D
Used Amate Audio DSP608 / DSP608D is a complete digital loudspeaker management system built for both touring and fixed sound installation markets, featuring 64-bit floating point DSP and high-performance 24-bit analogue converters. The DSP608D variant adds Dante networking via its Ethernet connector. Browse the second-hand Amate Audio DSP608 / DSP608D listings currently available by scrolling down.
No listings currently in stock. This page stays live — check back or register interest.
0 listed right now — list yours to the buyers searching this model.
Get an email when a new Amate Audio DSP608 / DSP608D is listed.
Amate Audio DSP608 / DSP608D specifications
| Brand | Amate Audio |
| Segment | Audio |
About the Amate Audio DSP608 / DSP608D
The Amate Audio DSP608 / DSP608D is a digital loudspeaker management system offering 4 analogue inputs, 2 digital AES/EBU inputs and 8 outputs with flexible routing, plus a 118 dB dynamic range on inputs and 114 dB on outputs. Its 64-bit floating point DSP delivers 1 Hz frequency resolution, 10 parametric equalizers per input and output, multiple crossover types including Butterworth, Bessel and Linkwitz-Riley up to 4th order, and up to 2 seconds of delay per channel. An RMS compressor, peak limiter, USB interface for PC/Mac control, Ethernet connection and storage for up to 100 program setups complete the feature set. The DSP608D adds 2 Dante inputs via the rear RJ-45 Ethernet connector.
Amate Audio DSP608 / DSP608D — buyer FAQs
What is the Amate Audio DSP608 and what does it do?
The Amate Audio DSP608 is a digital loudspeaker management system built for touring and fixed sound installation use. It provides 4 analogue inputs, 2 AES/EBU digital inputs and 8 outputs with flexible routing. Each input and output carries 10 parametric equalizers, multiple crossover types up to 4th order, up to 2 seconds of delay, an RMS compressor and a peak limiter, all processed through a 64-bit floating point DSP engine.
What is the difference between the DSP608 and the DSP608D?
The DSP608D includes all the features of the standard DSP608 and adds 2 Dante inputs delivered via the rear RJ-45 Ethernet connector. Both variants share the same analogue and AES/EBU input configuration, 8 outputs, 118 dB input dynamic range, 114 dB output dynamic range, 65 kHz sampling rate and 1 ms low latency operation.
What crossover and EQ options does the DSP608 offer?
The DSP608 provides 10 parametric equalizers per input and output channel, with filter types including Bell, Notch, High Shelf, Low Shelf, Allpass, Band Pass, High Pass and Low Pass. Crossover options cover Butterworth, Bessel and Linkwitz-Riley alignments up to 4th order at 24 dB per octave, with 1 Hz frequency resolution throughout.
What control and connectivity options are available on the DSP608 / DSP608D?
The unit offers a front-panel USB interface for PC and Mac control and configuration, a rear Ethernet connection via RJ-45, and a 2-line 16-character blue backlit LCD display with signal LEDs on every input and output. It stores up to 100 program setups and includes a security lock. CPU and DSP firmware can be upgraded through the PC/Mac interface.
What should I check when buying a used Amate Audio DSP608 / DSP608D?
Confirm whether the unit is a DSP608 or DSP608D, since the Dante input capability is specific to the D variant. Check that all 8 outputs, both AES/EBU inputs and the USB and Ethernet ports are functioning, and verify how many of the 100 program setup slots have been used and whether they can be cleared. Used units are covered by 10K Used's 21-day warranty for major functional faults; full details are in the buying guide at https://www.10kused.com/used-av-equipment-guide/.
