Used Electrovoice PX2122
Used Electrovoice PX2122 units are available here as second-hand examples of this high-efficiency 12-inch two-way loudspeaker system from the Electro-Voice Phoenix Series, offering 1000W continuous power handling, 138 dB maximum SPL, and a rotatable 45-degree by 30-degree coverage pattern designed for arrayed sound reinforcement. Scroll down to browse the current used PX2122 listings available on 10K Used.
No listings currently in stock. This page stays live — check back or register interest.
0 listed right now — list yours to the buyers searching this model.
Get an email when a new Electrovoice PX2122 is listed.
Electrovoice PX2122 specifications
| Brand | Electrovoice |
| Segment | Audio |
About the Electrovoice PX2122
The Electrovoice PX2122 is a 12-inch two-way dual manifolded full-range loudspeaker system configured for biamp operation and intended for high-output sound reinforcement in both fixed-installation and portable sound applications. It features dual DVX3121 12-inch LF transducers with forced air cooling in a vented enclosure, paired with dual ND2 1-inch exit neodymium compression drivers summed in a manifold for increased power handling, maximum SPL and lower distortion. Power handling is rated at 1000W continuous and 4000W peak, with a maximum SPL of 138 dB. The rotatable 45-degree by 30-degree horn provides long-throw tight coverage, and up to three units can be arrayed together for 135 degrees of horizontal coverage. The enclosure is built from 18-mm 13-ply plywood with tongue-and-groove joints and EVCoat finish, and includes integral rigging points for eyebolts or an optional rigging kit. The PX2122 reproduces frequencies above 80 Hz and is designed to be paired with the PX2181 subwoofer for a full-range three-way configuration.
Electrovoice PX2122 — buyer FAQs
What is the Electrovoice PX2122 and what is it designed for?
The Electrovoice PX2122 is a 12-inch two-way dual manifolded loudspeaker system configured for biamp operation. It is built for high-output sound reinforcement in fixed-installation and portable sound applications. The cabinet reproduces frequencies above 80 Hz, making it a main or mid-high array element rather than a standalone full-range system. Integral rigging points and a shared Phoenix Series footprint support multi-cabinet deployments.
Who makes the PX2122 and where does it sit in their loudspeaker range?
The PX2122 is made by Electro-Voice, an American professional audio manufacturer founded in 1927 and known for loudspeakers, microphones and signal processing for sound reinforcement. The cabinet sits within the Phoenix Series, a line of enclosures sharing a common footprint designed to work together. Within that range the PX2122 acts as the mid-high element, intended to be combined with the PX2181 subwoofer for a full-range three-way configuration.
How many PX2122 cabinets can be arrayed together, and what coverage does that provide?
Up to three PX2122 cabinets can be arrayed together, producing 135 degrees of combined horizontal coverage. Each cabinet provides a 45-degree by 30-degree coverage pattern via a rotatable horn, so the orientation can be adjusted to suit the array geometry. The enclosure shares the same footprint as other Phoenix Series models, which simplifies consistent mechanical alignment when building larger arrays.
What drivers and power handling does the PX2122 use?
The PX2122 uses dual DVX3121 12-inch woofers with forced air cooling in a vented enclosure, and dual ND2 1-inch exit neodymium compression drivers summed in a manifold for lower distortion and higher headroom. Power handling is rated at 1000W continuous and 4000W peak, with a maximum SPL of 138 dB. The manifolded HF arrangement is intended to increase power handling and reduce distortion compared with a single driver.
What should I check when buying a second-hand PX2122?
Check that both 12-inch woofers move freely and produce no rattling or rubbing, and that both compression drivers reproduce high frequencies without distortion or dropout. Confirm the biamp input configuration is intact and that any rigging hardware is undamaged, since integral rigging points are a key feature. Ask whether an optional rigging kit is included. Every 10K Used listing carries a 21-day warranty covering major functional faults; full details are in the buying guide at 10kused.com/used-av-equipment-guide/.
