Used Fohhn LX-220

Fohhn LX-220

Main features and specification for Fohhn LX-220:

• 18 × 4" long excursion driver, 3 × 1" compression driver with Waveguide
• Nominal power rating: 900 W
• Dispersion: 130° × 15° (H × V)
• SPL max.: 131 dB
• Can be perfectly combined with Fohhn subwoofers
• High feedback resistance
• Connections: 8-pole Phoenix connector
• Optionally available as 100-volt version
• Available in RAL Classic, NCS or Pantone colors on request
• Photorealistic Fohhn Texture Design is optionally available
• Weatherproof aluminum enclosure and laminated speakers guarantee outdoor use
• In order to ensure performance and operational safety, Fohhn system amplifiers including the correct speaker preset are required.
• enclosure: weatherproof aluminium housing, powder coated, steel bracings
• front design: steel grille in enclosure colour, backed by acoustically transparent foam
• protection grille: steel grille, ball impact resistant, powder-coated
• weight: 16 kg
• standard colours: black (RAL 9005) or white (RAL 9016), powder coated
• mounting points: 12 × M6 threads
• connectors: 8-pin Phoenix terminal
• dimensions (W × H × D): approx. 130 × 2200 × 120 mm

The LX-220 is a passive 4-way line source speaker. It was developed to ensure top quality transmission of speech and music even in rooms with demanding acoustics, and it impresses with its exceptional reach.
The renowned Fohhn line source speakers combine the advantages of a line array – such as directionality, even dispersion and reach – in a single compact system. The slim aluminum housing enables perfect visual integration into the room architecture or stage design.
