Used High End XSpot Xtreme
Used High End XSpot Xtreme moving head lighting fixtures deliver 16,000 lumens of output alongside smooth CMY colour mixing, dual rotating gobo wheels, and a choice of two zoom lens configurations, making them a formidable option on the second-hand market. Browse the used XSpot Xtreme listings available below to find the right unit for your rig.
No listings currently in stock. This page stays live — check back or register interest.
0 listed right now — list yours to the buyers searching this model.
Get an email when a new High End XSpot Xtreme is listed.
High End XSpot Xtreme specifications
| Brand | High End |
| Segment | Lighting |
About the High End XSpot Xtreme
The High End XSpot Xtreme is a DMX-512 compatible moving head fixture with 16,000 lumens of brightness, described as surpassing competing fixtures in its category. It offers two zoom lens options with constant aperture and focus tracking, covering a 2:1 (15 to 30 degree) and a 4:1 (12 to 48 degree) range, plus 630 degrees of pan and 240 degrees of tilt with extremely smooth movement. A smooth CMY colour mixing system is complemented by a six-position dichroic colour wheel, variable colour temperature correction from 3000K to 7500K via CTO and CTB filters, and 16-bit gobo indexing. The standard configuration includes three modules: a colour mixing module, a dual rotating gobo module with two gobo wheels and stacking capability, and a rotating gobo and iris module. Additional features include Light Burst technology for temporary output increases, mechanical and electronic strobe, variable frost, variable iris, remote beam flatness adjustment, smooth linear dimming, and self-adjusting variable speed fans for quiet operation.
High End XSpot Xtreme — buyer FAQs
What is the High End XSpot Xtreme and what kind of fixture is it?
The High End XSpot Xtreme is a DMX-512 compatible moving head lighting fixture producing 16,000 lumens. It features 630 degrees of pan and 240 degrees of tilt, smooth CMY colour mixing, variable colour temperature correction from 3000K to 7500K, dual rotating gobo wheels with stacking capability, Light Burst technology, mechanical and electronic strobe, variable frost, variable iris, and self-adjusting variable speed fans for quiet operation.
Who makes the XSpot Xtreme and where does it sit in the High End Systems range?
The XSpot Xtreme is made by High End Systems, an American entertainment lighting manufacturer based in Austin, Texas, known for automated moving fixtures and the Hog family of lighting control consoles used in concerts, television and live events. Since 2017 the company has been owned by Electronic Theatre Controls (ETC). The XSpot Xtreme sits at the upper end of the High End moving head spotlight range, with its 16,000-lumen output positioned to surpass competing fixtures in its category.
What zoom lens options does the XSpot Xtreme offer?
The XSpot Xtreme offers two zoom lens options, both with constant aperture and focus tracking. The first is a 2:1 f1.4 six-element zoom covering 15 to 30 degrees. The second is a 4:1 f2.0 eleven-element zoom covering 12 to 48 degrees. The wider 4:1 option provides greater versatility for venues where beam angle needs to vary significantly across different positions or scenes.
What does the standard module configuration of the XSpot Xtreme include?
The standard configuration includes three modules: a colour mixing module with a six-position dichroic colour wheel carrying five replaceable colours plus open, a dual rotating gobo module with two gobo wheels offering seven rotating indexing LithoPatterns each plus open, and a rotating gobo and iris module also featuring seven rotating indexing LithoPatterns for effects layering. An effects wheel with rotating indexing glass effects in seven apertures is also included.
What should I check when buying a used second-hand XSpot Xtreme?
Verify that all three standard modules are present and functioning, confirm which zoom lens option is fitted (2:1 or 4:1), and test pan, tilt, gobo indexing, CMY mixing, iris, frost and strobe functions. Check that the Light Burst feature and variable speed fans operate correctly. Used units on 10K Used carry a 21-day warranty covering major functional faults; full details are in the buying guide at https://www.10kused.com/used-av-equipment-guide/.
