Used Luminex Ethernet-DMX2 MkII Range
Used Luminex Ethernet-DMX2 MkII Range units are professional Ethernet-to-DMX converters available in Truss and Wall variants, each capable of streaming up to 300 universes and supporting ArtNet, sACN and RTTrPL protocols with a custom merging engine. Second-hand examples are well suited to touring, live events, theatres and cruise ships. Browse the current used listings available on 10K Used by scrolling down.
No listings currently in stock. This page stays live — check back or register interest.
0 listed right now — list yours to the buyers searching this model.
Get an email when a new Luminex Ethernet-DMX2 MkII Range is listed.
Luminex Ethernet-DMX2 MkII Range specifications
| Brand | Luminex |
| Segment | Lighting |
About the Luminex Ethernet-DMX2 MkII Range
The Luminex Ethernet-DMX2 MkII Range comprises the Truss MkII and Wall MkII, both designed to convert Ethernet protocols including ArtNet, sACN and RTTrPL (BlackTrax) to DMX across up to 300 universes. Configuration is handled through an easy-to-use web interface that supports pre-configured setup profiles, while full RDM support allows centralised device management via LumiNet Monitor. Both variants feature metal housing with ruggedized Ethercons and shielded DMX connectors. The Truss MkII can be powered via PoE or a standard power cable, making it ideal for touring and live events, while the Wall MkII is PoE-only and is suited to permanent installations such as theatres and cruise ships.
Luminex Ethernet-DMX2 MkII Range — buyer FAQs
What is the Luminex Ethernet-DMX2 MkII Range and what does it do?
The Luminex Ethernet-DMX2 MkII Range is a family of professional Ethernet-to-DMX converters available in two variants: the Truss MkII and the Wall MkII. Both convert protocols including ArtNet, sACN and RTTrPL (BlackTrax) to DMX, supporting up to 300 universes. A custom merging engine allows different sources to control specific fixture parameters simultaneously, and full RDM support enables centralised device management through LumiNet Monitor.
What is the difference between the Ethernet-DMX2 Truss MkII and the Wall MkII?
The Truss MkII is built for touring and live events, with metal housing, ruggedized Ethercons and shielded DMX connectors, and can be powered either via PoE or a standard power cable. The Wall MkII shares the same protocol support and merging capabilities but is designed for permanent installations such as theatres and cruise ships, and is powered by PoE only, removing the need for a separate power connection.
Who makes the Ethernet-DMX2 MkII Range?
The Ethernet-DMX2 MkII Range is made by Luminex. Both the Truss MkII and Wall MkII are positioned within Luminex's professional lighting networking product line, targeting demanding environments from touring productions to fixed installations in venues such as theatres and cruise ships.
What should I check when buying a used Luminex Ethernet-DMX2 MkII Range unit?
Confirm which variant you are buying, Truss MkII or Wall MkII, since their power options differ. Check that the ruggedized Ethercon and shielded DMX connectors are undamaged, and verify that web interface access and PoE power work correctly. Used units on 10K Used carry a 21-day warranty covering major functional faults; full details are in the buying guide at 10kused.com/used-av-equipment-guide/.
What protocols does the Ethernet-DMX2 MkII support, and how is it configured?
Both MkII variants support ArtNet, sACN and RTTrPL (BlackTrax) for conversion to DMX across up to 300 universes. Configuration is handled through a web interface that allows pre-configured setup profiles to be loaded quickly. The custom merging engine lets operators assign different Ethernet sources to control specific fixture parameters, and all connected lighting devices can be monitored centrally via LumiNet Monitor with full RDM support.
