Used MA Lighting dimMA module 1 x 11.5kVA 400µs
Used MA Lighting dimMA module 1 x 11.5kVA 400µs is a digital dimming system designed specifically for permanent installations, offering plug-in dimmer modules in multiple power ratings and dual independent control inputs via Ethernet and DMX. Built on the reliability of MA touring dimmers, it brings that heritage into fixed installation environments. Scroll down to browse second-hand dimMA module listings currently available on 10K Used.
No listings currently in stock. This page stays live — check back or register interest.
0 listed right now — list yours to the buyers searching this model.
Get an email when a new MA Lighting dimMA module 1 x 11.5kVA 400µs is listed.
MA Lighting dimMA module 1 x 11.5kVA 400µs specifications
| Brand | MA Lighting |
| Segment | Lighting |
About the MA Lighting dimMA module 1 x 11.5kVA 400µs
The MA Lighting dimMA module 1 x 11.5kVA 400µs is a plug-in dimmer module rated at 11,500VA, designed for use within the dimMA digital dimming system for permanent installations. Cabinets based on Rittal 19-inch rack enclosures have a footprint of just 600 x 600mm and can be populated with modules across three power ratings: 3,000VA, 5,700VA or 11,500VA. Each dimmer features current sensing and fault feedback via Ethernet as standard, with load check, control checking and LED fault indication per circuit. Two independent signal inputs via Ethernet and DMX are supported, with LTP, HTP and backup link options, two separate DMX A and B inputs with Thru output, and an optional second processor for synchronous backup.
MA Lighting dimMA module 1 x 11.5kVA 400µs — buyer FAQs
What is the MA Lighting dimMA module 1 x 11.5kVA 400µs and what is it designed for?
The MA Lighting dimMA module 1 x 11.5kVA 400µs is a plug-in digital dimmer module rated at 11,500VA, built specifically for permanent installations. It slots into 19-inch Rittal rack cabinets with a 600 x 600mm footprint, which can be populated with a mix of module types across three power ratings. Each module includes current sensing and fault feedback via Ethernet as standard, with LED fault indication per circuit.
Who makes the dimMA system and where does this module fit in the MA Lighting range?
The dimMA system is made by MA Lighting International GmbH, a German lighting control manufacturer founded in 1983. MA Lighting is best known for the grandMA family of consoles used in concerts, theatre and large-scale events. The dimMA range brings the reliability established in MA touring dimmers into fixed installation environments, with this 11,500VA module sitting at the top of the three available power ratings alongside 3,000VA and 5,700VA variants.
What control signal options does the dimMA module support?
The dimMA module supports two independent signal inputs via Ethernet and DMX. Two separate DMX A and B inputs are provided with a Thru output for chaining additional cabinets. LTP, HTP and backup link configurations are all possible for the control input. When controlled via Ethernet, the system can convert and output two DMX lines, and an optional second processor is available as a synchronous backup.
What should I check when buying a used dimMA module 1 x 11.5kVA 400µs?
Confirm the module's power rating matches your installation requirement, as dimMA cabinets can hold a mix of 3,000VA, 5,700VA and 11,500VA modules. Check whether a main circuit-breaker and residual current device are included with any cabinet being sold alongside it. Verify that current sensing, fault feedback and LED indicators are all functioning. Used listings on 10K Used carry a 21-day warranty covering major functional faults; full details are in the buying guide at 10kused.com/used-av-equipment-guide/.
What drives the price of a used MA Lighting dimMA module 1 x 11.5kVA 400µs?
Pricing for a used dimMA module 1 x 11.5kVA 400µs varies with the module's condition, its age and whether it is sold alone or as part of a populated cabinet. The inclusion of a second processor backup option or additional cabling can also affect value. Check the live listings on this page for current second-hand pricing, as availability and configuration differ between units.
