Used Martin Audio W8L Longbow
Used Martin Audio W8L Longbow units are large-scale, three-way line array enclosures built for outdoor festivals, sports stadiums and the largest indoor arenas. As an evolution of the W8L system, the W8L Longbow delivers extended low-frequency performance down to 35Hz alongside consistent 90-degree horizontal pattern control across the mid and high frequencies. Browse the second-hand Martin Audio W8L Longbow listings available below to find the right unit for your application.
No listings currently in stock. This page stays live — check back or register interest.
0 listed right now — list yours to the buyers searching this model.
Get an email when a new Martin Audio W8L Longbow is listed.
Martin Audio W8L Longbow specifications
| Brand | Martin Audio |
| Segment | Audio |
About the Martin Audio W8L Longbow
The Martin Audio W8L Longbow is a large-scale, three-way line array enclosure designed for demanding live sound reinforcement and fixed installation applications including outdoor concerts, stadiums and large arenas. Its horn-loaded 15-inch hybrid bass horn section is rated at 106dB at 1W/1m per cabinet, while the twin 8-inch mid-horn delivers 109dB and the quad 1-inch HF horn reaches 119dB under the same conditions. An ultra-long excursion LF driver displaces nearly twice the air volume of its predecessor, extending the low-frequency response to a -3dB point of 35Hz. The W8L Longbow features a fast integral rigging system with variable splay angles, ViewPoint array optimisation software, factory controller presets and compatibility with W8LS, WLX, WSXa and WS218X subwoofer configurations.
Martin Audio W8L Longbow — buyer FAQs
What is the Martin Audio W8L Longbow and what venues is it designed for?
The Martin Audio W8L Longbow is a large-scale, three-way line array enclosure built for outdoor festivals, sports stadiums and the largest indoor arenas, as well as fixed installation projects. It is an evolution of the W8L system, with the core development being an ultra-long excursion 15-inch hybrid bass horn that displaces nearly twice the air volume of its predecessor and extends low-frequency output to a -3dB point of 35Hz.
What are the sensitivity ratings for each driver section of the W8L Longbow?
Each W8L Longbow cabinet delivers 106dB at 1W/1m from the horn-loaded 15-inch LF section, 109dB from the twin 8-inch mid-horn, and 119dB from the quad 1-inch HF horn under the same conditions. Horizontal pattern control is consistent at 90 degrees across the mid and high frequencies, which is a key characteristic for even coverage in large venues.
What subwoofer and bass extension systems is the W8L Longbow compatible with?
The W8L Longbow is compatible with the W8LS when flown or ground stacked, and with the WLX, WSXa and WS218X when ground stacked. Factory controller presets are available for a wide variety of configurations, and ViewPoint array optimisation software is included to assist with system design and alignment across these combinations.
Who makes the W8L Longbow and where does it sit in the Martin Audio range?
The W8L Longbow is made by Martin Audio, a British loudspeaker manufacturer founded in 1971 by Dave Martin and based in High Wycombe, England, and part of the Focusrite Group since 2019. Within the range it sits as the large-scale touring and installation line array, positioned above the W8L it evolved from and intended for the most demanding outdoor and stadium-scale reinforcement work.
What should I check when buying a used W8L Longbow?
Check the condition of all three driver sections individually, since the LF, mid and HF sections have distinct sensitivity ratings and any one underperforming cabinet will affect array consistency. Inspect the integral rigging hardware and variable splay angle components for wear or damage, as these are critical for safe flown deployment. Confirm whether ViewPoint software and factory controller presets are included. Used listings on 10K Used carry a 21-day warranty covering major functional faults; the buying guide at 10kused.com/used-av-equipment-guide/ has further detail.
