Used LDR Xpress 26 dmx/rdm

LDR Xpress 26

Main features and specification for LDR Xpress 26:

• Construction: sturdy aluminium housing
• Paint/Finish: black epoxy powder paint
• Rear mounting plate: 313x313mm – 12,32X12,32in, included
• Barndoor slots: 4, to accept a 313x313mm / 12,32x12,32in plate
• Safety cable: black, 60cm / 23 5/8in, supplied with the scroller
• Front opening dimensions: ø270mm – 10,62in
• DC power input: 24 V DC
• Power consumption: 13 W
• Current requirement: 0,7 amps (24V DC)
• Gel string capacity: 8, 11,16 and 21 frames. At power on, the unit automatically detects the number of frames mounted
• Gel string movement: step or continuous mode; the scroll speed can be set on the unit or remotely using the optional Speed channel.
• Scroll speed: min. 3,2 sec (head to tail, 21 frames)
• Gel string cooling system: double fan with 5 preset variable speeds or remotely controlled using a dedicated channel
• Motor: 2 DC servo motors directly fixed to the rollers (NO GEAR BOX)
• DMX/Power in: XLR 4-pin male - DMX 512 and 24V DC power
• DMX/Power out: XLR 4-pin female - DMX 512 and 24V DC power
• Daisy chaining: up to 6 units per power distribution unit (PDU6)
• LED status indicators: Red = power. Green = system, Yellow = signal
• DMX channels: min. 1, up to 4 more channels required if remote selection of Reset, Scroll Speed, Fan Speed or Operational Modes are used.
• Operational modes: continuous or step, selectable by pressing the UP and DOWN buttons
• Head + tail colour filter size: 706mm (W) x 281mm (H) – 27,79in (W) x 11,06in (H)
• Central frames col. filter size: 416mm (W) x 281mm (H) – 16,37in (W) x 11,06in (H)
• DMX power/control cable not supplied. High quality shielded twist pair type cable with XLR-4 pin connectors are accessories
• Net/packed weight: 3,4 kg / 4,0 kg - 7,50lb / 8,82lb
• Packed volume: 0.02m3 - 0,07in3

The Xpress 26, DMX515/RDM controllable scroller, is designed for use with those 2000W LDR fixtures featuring a 245x245mm/9.64x9.64 in colour frame, or any luminaire with a front aperture up to 270mm (10.62 in).

The Xpress 26 is delivered with 21-colour LEE filter gel string, 313x313mm (12.32x12.32 in) rear mounting plate and steel safety cable.

It also features 4 front attachments for a rotating barndoor, available as an optional accessory. A large selection of standard and customized rear mounting plates is available on request.
