Used Soundcraft Spirit LX7

The Soundcraft Spirit LX7 is a compact live mixing console with basic recording-oriented features, designed for multi-purpose use in small halls, community centres and similar venues. Its direct channel outputs on the first 16 mono inputs also make it a practical choice for bands needing a live desk that can double in the studio. One person can carry it, making it well suited to touring and smaller installations.

The Spirit LX7 is made by Soundcraft, a British professional audio brand founded in 1973 and part of Harman International since 1988. The LX7 sits at the accessible end of Soundcraft's analogue console range, combining the brand's live mixer fundamentals with recording-friendly features in a compact, portable frame aimed at engineers working across venues and studio environments.

The Spirit LX7 is available in 16, 24 or 32 channel frame sizes, accommodating 24, 32 or 40 inputs respectively, including stereo inputs and returns. The console provides 7 separate bus outputs, covering mix, 4 groups and a dedicated mono bus. Adding direct outputs on the first 16 mono inputs and six auxiliary buses brings the total output count to 29.

Each channel carries 4-band EQ with two swept mid-frequency controls, an EQ In/Out switch and an 18 dB/octave high-pass filter. Balanced mic inputs use Ultramic preamps offering 60 dB of gain range and 22 dBu of headroom. Six auxiliary sends are pre/post switchable in pairs, allowing up to 4 pre-fader and 6 post-fader sends. The console also features 100 mm faders, 12-segment LED metering and an integral PSU.

Confirm the frame size, since used units appear in 16, 24 and 32 channel configurations, each offering a different input count. Check that faders, EQ controls, phantom power and all six auxiliary sends are fully operational, and verify the condition of the integral PSU. Listings on this page show the current condition and configuration of each available unit. Every 10K Used listing carries a 21-day warranty covering major functional faults; full details are in the buying guide at 10kused.com/used-av-equipment-guide/.
